TEST CENTER

Les Fromentaux

Les Fromentaux started as a military zone created in 1917 to stock ammunition. The camp fell into disuse in 2004 and about 50 buildings were deserted. A surface area spanning over 80 hectares was the perfect location to establish our testing activity. Les Fromentaux underwent extensive renovations and was fitted out with all the latest technologies as well as a modern laboratory and a number of crash-test areas.

Transpolis is headquartered at Les Fromentaux: 620 route des Fromentaux 01500 Saint Maurice-de-Rémens, France.

City area+

Highway+

Rural roads+

Crash-test+

Facilities for Customers+

City section

+

City area

  • About 30 hectares, 12km of urban streets
  • 2 boulevards – about 500 meters long, with 6 lanes, T1 French axial marking. Bus and cycle lanes created on request.
  • 4 sections with different layouts: intersections / crossroads / winding streets / parking slots / double bends…
  • Ring road: 1755 meters around the City Area, 3 lanes, with 4 access lanes.
  • 40 buildings: a veritable city with real buildings to test connectivity (LOS/NLOS scenarios)
  • Containers: showing buildings with another component
  • Adjustable acilities: 60 fiber optic cabinets – roving sidewalk and façades - EV charging station - changing-message sign
  • Road equipment: movable signs – traffic lights with GLOSA services - bumpers – roundabouts – bus stops
  • Road marking: traffic lanes – crosswalks – luminescent lanes
  • Range of driving environments: surfaces (asphalt, paved streets, damaged road) – vegetation – sloping
  • Modular zone covering 7000 m2 – parking or event area

+

Highway

  • ADAS sensor area
  • 1000 meters long
  • 5 lanes (can be widened to 9 lanes)
  • All lane markings comply with the Euro NCAP test protocol for Lane Support Systems
  • Road markings: modularity, can be country-tailored, selection of colors, cross-sectional camber, roads…
  • Facilities: signs, 5 fiber optic cabinets, rockfall embankment for safety and privacy

+

Rural roads

  • Driving area covering 21,819 m2
  • 2.9 kilometers long – 2 lanes
  • Wide curves
  • 2 large traffic circles
  • Handling platform
  • French and German secondary roads
  • Curvature: from 30 to 157m
  • 6 fiber optic cabinets

+

Crash-test

3 crash test areas, each with:

  • Rockfall embankment for safety and privacy
  • Cameras, including travel cam
  • Drones
  • Cottage reserved for customers

Specific features:

  • Crash Test Area 1: EN1317 / AASHTO MASH crash tests
    Area length: 150m
    Surface: compacted gravel and asphalt
  • Crash Test Area 2: HVM / EN1317 crash tests
    Launch pad: 732m - Angle: frontal
    Surface: as required by customers.
  • Crash Test Area 3: EN1317 / AASHTO MASH crash tests
    Area length: 200m
    Surface: compacted gravel, asphalt & concrete (bridge)

State-of-the-art facilities

+

Reserved for customers

  • 3 workshops with pit
  • Meeting rooms
  • Supervisor Building in the City Area: 2 meeting rooms + 360° platform balcony
  • Building restored as storage area for equipment and vehicles

+

Secure infrastructures

  • Risk analysis
  • Safety briefing
  • Personalised support
  • Private areas behind closed doors with security gates
  • More than 30 cameras
  • Security control office

+

Fully connected

  • Mesh optical network + optical ring road
  • Network and energy access points (60 connection terminal)
  • More than 70 fiber optical cabinets – external power supply: 220 volts (can be increased to 380 volts)
  • Proprietary Mobile Network including new 5G technology (Transpolis is a pilot for 5G connectivity since 2018)

Technologies :

  • V2X
  • DSRC: ITS-G5 / LTE-V2X
  • Bluetooth / Wifi
  • BLE
  • ZigBee
  • IoT
